MESH SWITCHES
The bridge between cabinet equipment and the Mesh
The bridge between cabinet equipment and the Mesh
Local Mesh Switchs provide connectivity to equipment mounted in roadside cabinets (such as OTUs / modems) as well as backhaul capabilities. These switches act as gateways to the Mesh 4G network for non-mesh equipment to be routed.
Mesh Switch for connecting cabinet mounted equipment to the mesh network.,with passive PoE out.
5 Gigabit ports
4 Passive PoE ports
MCP Functions, mChannel
Throughput 1.2 Gbps Max
Temp Range -40º to 70ºC
Mains Power Supply
Support ADSL/VDSL Modems
Mesh Switch for connecting cabinet mounted equipment to the mesh network, with additional 4G backhaul capability.
5 Gigabit ports
4G Modem
MCP Functions, mChannel
Throughput 1.2 Gbps Max
Temp Range -40º to 70ºC
Mains Power Supply
Support ADSL/VDSL Modems
Mesh Switch for connecting cabinet mounted equipment to the mesh network, with with ADSL/VDSL model for back-haul sites.
5 Gigabit ports
ADSL/VDSL High speed Internet
MCP Functions, mChannel
Throughput 1.2 Gbps Max
Temp Range -40º to 70ºC
Mains Power Supply
Support ADSL/VDSL Modems
Mesh Switch for connecting cabinet mounted equipment to the mesh network, with 4 additional ports and 4 SFP ports for expansion.
8 Gigabit ports
4 SFP Ports
MCP Functions, mChannel
Throughput 1.2 Gbps Max
Temp Range -40º to 70ºC
Mains Power Supply
Support ADSL/VDSL Modems
(SFP modules not included)
Universal SFP Transceiver
For 1000BASE-LX Ethernet links
Supported Data Rates: 1.05 Gbit/s - 1.25 Gbit/s
Up to 20 km via Singlemode OS2
LC-Connector
Operating Temperature from -40°C to 85°C, Digital Diagnocstic Monitoring (DDM)
Mesh Switch for connecting cabinet mounted equipment to the mesh network.
5 Gigabit ports
MCP Functions, mChannel
Throughput 1.2 Gbps Max
Temp Range -40º to 70ºC
Mains Power Supply
Support ADSL/VDSL Modems
